3D Vision and geo-11 fix for DuckStation, a PlayStation emulator. Separate fixes for the "Hardware (D3D11)" (3D Vision and geo-11 fixes) and "Hardware (Vulkan)" renderer.
This is possible thanks to the PGXP feature that improves geometry and texture accuracy. It makes geometry vertices have a real depth value, which can be used for stereoscopic 3D.
Fixed in DirectX 11 with 3Dmigoto and geo-11.
Fixed in Vulkan with Vk3DVision.
Update (2023-10-25): updated geo-11 version to v0.6.182. Apparently now "nvidia_dx9" mode works too, and the nogui version of the emulator doesn't exist anymore. For geo-11, the normal qt version is OK.
Update (2022-07-27): added geo-11 fix. For those with 3D Vision monitors that want to use new GPUs or drivers, I recommend using the Vk3DVision fix.
Update (2022-02-20): reuploaded both DX11 and Vulkan fixes. The Vulkan one is updated to Vk3DVision version 4.19.19. The point of this update in general was making the separation settings equal between DX11 and Vulkan.
Update (2021-12-03): reuploaded Vulkan fix, after seeing that when Vk3DVision doesn't have dev mode enabled, a few games can crash (Vagrant Story, for example).
Update (2021-12-01): added fix for Vulkan made in single frame stereo. For Nvidia GPUs, the 2000 series is required as minimum and also newer drivers than the last ones that can be used with DX11.
What the fix does
- It stereoizes geometry, because even in DX11, 3D Vision Automatic doesn't stereoize anything.
- It has a hotkey with depth options for elements that are detected as 2D (could be HUD, could be skyboxes, could be wrong 2D geometry). Divided into multiple hotkeys in Vulkan.
- It has a hotkey for black frame insertion (only for DX11). Most likely annoying for most people. It has the purpose of making 30fps games look smoother (no double images at 60Hz when tracking elements with your eyes).
Known issues (Common)
- Some games detect part of the geometry as 2D (PGXP can't improve them), and as a consequence they can't have proper depth in 3D. It's usually geometry that is close to the camera, in the games affected by this problem. Examples: Ape Escape, Spyro games, Medievil games.
- Sprites that should be inside the game world may appear in 2D (they can be moved with a hotkey, but it won't be accurate depth). Examples: Dragon Quest VII, Tomba!.
Known issues (Vulkan)
- You're forced to use the "duckstation-nogui-x64-ReleaseLTCG.exe" of DuckStation, because Vk3DVision crashes just by launching a game with the interface of the other exe. This is why I recommend configuring everything first with the other exe and then setting some hotkeys to open the quick menu, decrease and increase resolution, etc.
- You're forced to use the "duckstation-nogui-x64-ReleaseLTCG.exe" of DuckStation, because Vk3DVision crashes just by launching a game with the interface of the other exe. This is why I recommend configuring everything first with the other exe and then setting some hotkeys to open the quick menu, decrease and increase resolution, etc.
- The "Multisample Antialiasing" option doesn't work in 3D. It's inside "Settings -> Advanced Settings". It's fine in DX11.
- Fast forwarding can make convergence reset to default.
Installation (DX11)
- Don't use Windows 7. The fix relies on flip model, which the emulator uses by default. That feature should work on Windows 8 and newer.
- Get the latest emulator version for Windows x64 from github.
- geo-11 (with build v0.6.182): download this file and extract its contents in the "duckstation-windows-x64-release" folder, where "duckstation-qt-x64-ReleaseLTCG.exe" is. Remember to edit "d3dxdm.ini" to change your "direct_mode" to the output you need. It's sbs by default. For 3D Vision monitors, both "direct_mode = nvidia_dx11" and "nvidia_dx9" work but "nvidia_dx9" may have imperfect vsync.
- 3D Vision (old alternative): download this file and extract its contents in the "duckstation-windows-x64-release" folder, where "duckstation-qt-x64-ReleaseLTCG.exe" and "duckstation-nogui-x64-ReleaseLTCG.exe" are.
- To configure the emulator easily, use "duckstation-qt-x64-ReleaseLTCG.exe" to your liking, but there are some key components for stereoscopic 3D. I'm going to mention them even if some of them are correct by default:
- To configure the emulator easily, use "duckstation-qt-x64-ReleaseLTCG.exe" to your liking, but there are some key components for stereoscopic 3D. I'm going to mention them even if some of them are correct by default:
- Settings -> Display Settings -> Basic -> Renderer -> Hardware (D3D11)
- Settings -> Display Settings -> Basic -> Fullscreen Mode -> Borderless Fullscreen
- Settings -> Display Settings -> Basic -> Use Blit Swap Chain -> Off
- Settings -> Enhancement Settings -> PGXP -> Geometry Correction -> On
- Settings -> Enhancement Settings -> PGXP -> Texture Correction -> On
Metal Gear Solid also needs "Settings -> Enhancement Settings -> PGXP -> CPU Mode (Very Slow) -> On".
- Run the game you want. The first time, in 3D Vision modes, Windows will ask for permission to modify the Nvidia profile.
Installation (Vulkan)
- Get the latest emulator version for Windows x64 from github.
- Get the latest emulator version for Windows x64 from github.
- Download this file and extract its contents anywhere you want (it can be the emulator folder or not).
- To configure the emulator easily, use "duckstation-qt-x64-ReleaseLTCG.exe" to your liking, but there are some key components for stereoscopic 3D. I'm going to mention them even if some of them are correct by default:
- To configure the emulator easily, use "duckstation-qt-x64-ReleaseLTCG.exe" to your liking, but there are some key components for stereoscopic 3D. I'm going to mention them even if some of them are correct by default:
- Settings -> Display Settings -> Basic -> Renderer -> Hardware (Vulkan)
- Settings -> Display Settings -> Basic -> Fullscreen Mode -> Borderless Fullscreen
- Settings -> Display Settings -> Basic -> Use Blit Swap Chain -> Off
- Settings -> Enhancement Settings -> PGXP -> Geometry Correction -> On
- Settings -> Enhancement Settings -> PGXP -> Texture Correction -> On
- Open "Profiles\DuckStation\Vk3DVision.ini" and set your preferred "Stereo3DViewMode" depending on your type of display. It's configured as "Stereo3DViewMode = 3DVision" by default. You can also set your preferred default separation and convergence.
- Run "Vk3DVision.exe" and then "duckstation-nogui-x64-ReleaseLTCG.exe". The emulator should trigger 3D and run in fullscreen. Then load the game you want.
Hotkeys (DX11)
- p: convergence presets (0, 0.5, 1, 2, 3, 4, 8, 16). 1 by default. Different games need different convergence levels.
- o: depth presets for 2D elements (0%, 25%, 50%, 62.5%, 75%, 85%, 100%). 0% depth by default.
- i: maximum depth settings (x0.325, x0.4225, x0.4875, x0.56875, x0.62), because some games have more effective separation than others. x0.325 by default.
- u: black frame insertion, intended for 30fps games. I don't recommend using it because it flickers a lot. One press enables it, another press makes the opposite frame black (which one has less latency may vary), and another press disables it. Disabled by default.
Hotkeys (Vulkan)
- 1,2,3,4,5,6 (not the numpad): convergence presets (0, 0.5, 1, 2, 3, 4). 1 by default. Different games need different convergence levels.
- g,h,j,k,l: depth presets for 2D elements (0%, 50%, 70%, 85%, 100%). 0% depth by default.
- y,u,i,o,p: maximum depth settings (x0.5, x0.65, x0.75, x0.875, x1.0), because some games have more effective separation than others. x0.5 by default. The numbers here are different than the DX11 ones, but the effective separation is the same.
- 1,2,3,4,5,6 (not the numpad): convergence presets (0, 0.5, 1, 2, 3, 4). 1 by default. Different games need different convergence levels.
- g,h,j,k,l: depth presets for 2D elements (0%, 50%, 70%, 85%, 100%). 0% depth by default.
- y,u,i,o,p: maximum depth settings (x0.5, x0.65, x0.75, x0.875, x1.0), because some games have more effective separation than others. x0.5 by default. The numbers here are different than the DX11 ones, but the effective separation is the same.
- m: reset to default status of the hotkeys.
Recommendations (DX11)
- (For the old 3D Vision fix, not geo-11) To avoid one eye bugs (which can be solved by loading a savestate anyway), configure everything with "duckstation-qt-x64-ReleaseLTCG.exe" but then play the games with "duckstation-nogui-x64-ReleaseLTCG.exe", because 3D will be enabled during the entire session, even inside menus, so bugs like that one can't happen. It may be too annoying to navigate this UI if you prefer the other interface.
- (For the old 3D Vision fix, not geo-11) To avoid one eye bugs (which can be solved by loading a savestate anyway), configure everything with "duckstation-qt-x64-ReleaseLTCG.exe" but then play the games with "duckstation-nogui-x64-ReleaseLTCG.exe", because 3D will be enabled during the entire session, even inside menus, so bugs like that one can't happen. It may be too annoying to navigate this UI if you prefer the other interface.
- If you have a powerful GPU, use a high "Internal Resolution Scale" setting in combination with the advanced setting "Multisample Antialiasing" set to some SSAA value.
- I don't recomment using any other "Texture Filtering" other than "Nearest-Neighbor". At least in Vagrant Story, I saw the motion blur effect being rendered black with other settings.
- For easy widescreen mode, go to Display Settings and set Aspect Ratio to "Auto (Match Window)" and enable the Widescreen Hack in the Enhancement settings.
- Enable all PGXP settings except Depth Buffer and CPU Mode. CPU Mode is needed for Metal Gear Solid, but it can cause issues in other games.
- Don't force vsync through the drivers, because the fast forward key in the emulator can't bypass it. Instead, use vsync in the emulator (Display Settings).
Recommendations (Vulkan)
- Since you need to play using the DuckStation exe that has a more limited interface, I recommend setting the hotkey that opens the quick menu, and also others to increase and decrease resolution, for example.
- Since you need to play using the DuckStation exe that has a more limited interface, I recommend setting the hotkey that opens the quick menu, and also others to increase and decrease resolution, for example.
- Don't alt+tab or alt+enter. You risk a crash.
- Force vsync in the drivers. I needed it despite having it enabled in the emulator. But this makes fast forward do nothing.
If you liked the fix and want to contribute for more future fixes, you can donate to this PayPal account: masterotakusuko@gmail.com
